Hycal latest software (5.16) / firmware (4.33)

Downloads

Access user manuals, software, technical documentation, and product brochures for Hycal hydrogen analysis systems.

Hycal User Manual

Hycal User Manual

Manuals
V2.7

Complete user manual for Hycal devices with detailed operating instructions and specifications.

Download
Hycal Mini User Manual

Hycal Mini User Manual

Manuals
V2.0

User manual specifically for the Hycal Mini portable hydrogen analyzer.

Download
Hycal PC Software

Hycal PC Software

Software
2.09

PC software for data logging and analysis with Hycal devices.

Download
Hycal Mini PC Software

Hycal Mini PC Software

Software
1.17

Legacy PC software for Hycal Mini Mk1 / Mk2

Download
ISO 9001:2015 Certificate

ISO 9001:2015 Certificate

Certificates
Valid until 31 May 2027

EMC Ltd certification for quality management systems in design, development, and production.

Download
Hycal Probe Simulator

Hycal Probe Simulator

Technical Notes
14/08/23

Technical documentation for Hycal probe simulator operation and signal limits.

Download
Hycal Product Brochure

Hycal Product Brochure

Brochures

Comprehensive brochure covering Hycal hydrogen analysis solutions for molten metal applications.

Download

Technical Drawings

Probe cable

HYC.CBL.LEN.012.616

Drawing Number:3B1640
Description:Probe connection cable
Length:1.2m

HYC.CBL.LEN.020.617

Drawing Number:3B1640
Description:Probe connection cable
Length:2m

HYC.CBL.LEN.030.618

Drawing Number:3B1640
Description:Probe connection cable
Length:3m

HYC.CBL.LEN.050.619

Drawing Number:3B1640
Description:Probe connection cable
Length:5m

HYC.CBL.LEN.080.620

Drawing Number:3B1640
Description:Probe connection cable
Length:8m

HYC.CBL.LEN.100.621

Drawing Number:3B1640
Description:Probe connection cable
Length:10m

HYC.CBL.LEN.120.622

Drawing Number:3B1640
Description:Probe connection cable
Length:12m

HYC.CBL.LEN.150.623

Drawing Number:3B1640
Description:Probe connection cable
Length:15m

HYC.CBL.LEN.200.624

Drawing Number:3B1640
Description:Probe connection cable
Length:20m

HYC.CBL.LEN.012.637

Drawing Number:3B1650
Description:Probe cable straight
Length:1.2m

HYC.CBL.LEN.020.638

Drawing Number:3B1650
Description:Probe cable straight
Length:2m

HYC.CBL.LEN.030.639

Drawing Number:3B1650
Description:Probe cable straight
Length:3m

HYC.CBL.LEN.035.640

Drawing Number:3B1650
Description:Probe cable straight
Length:3.5m

HYC.CBL.LEN.050.641

Drawing Number:3B1650
Description:Probe cable straight
Length:5m

HYC.CBL.LEN.080.642

Drawing Number:3B1650
Description:Probe cable straight
Length:8m

HYC.CBL.LEN.080.648

Drawing Number:3B1650
Description:Probe cable straight
Length:8m

HYC.CBL.LEN.100.643

Drawing Number:3B1650
Description:Probe cable straight
Length:10m

HYC.CBL.LEN.120.644

Drawing Number:3B1650
Description:Probe cable straight
Length:12m

HYC.CBL.LEN.150.645

Drawing Number:3B1650
Description:Probe cable straight
Length:15m

HYC.CBL.LEN.200.646

Drawing Number:3B1650
Description:Probe cable straight
Length:20m

HYC.CBL.LEN.030.650

Drawing Number:3B1655
Description:Probe extension cable
Length:3m

HYC.CBL.LEN.050.651

Drawing Number:3B1655
Description:Probe extension cable
Length:5m

HYC.CBL.LEN.100.652

Drawing Number:3B1655
Description:Probe extension cable
Length:10m

HYC.CBL.LEN.120.653

Drawing Number:3B1655
Description:Probe extension cable
Length:12m

HYC.CBL.LEN.150.654

Drawing Number:3B1655
Description:Probe extension cable
Length:15m

HYC.CBL.LEN.200.655

Drawing Number:3B1655
Description:Probe extension cable
Length:20m

Hycal probe

Key

  • [MFC] — For use with devices that include a Mass Flow Controller (MFC)
  • [R] — For use with devices that do not include a Mass Flow Controller

HYC.PRB.003.005.1095

Drawing Number:3B1515
Description:Hycal Probe 500mm [MFC]
Ceramic Length:300mm
Total length:500mm

HYC.PRB.003.005.256

Drawing Number:3B1515
Description:Hycal probe 500mm [R]
Ceramic Length:300mm
Total length:500mm

HYC.PRB.003.008.1096

Drawing Number:3B1515
Description:Hycal probe 800mm [MFC]
Ceramic Length:300mm
Total length:800mm

HYC.PRB.003.008.255

Drawing Number:3B1515
Description:Hycal probe 800mm [R]
Ceramic Length:300mm
Total length:800mm

HYC.PRB.003.010.1097

Drawing Number:3B1515
Description:Hycal probe 1000mm [MFC]
Ceramic Length:300mm
Total length:1000mm

HYC.PRB.003.010.565

Drawing Number:3B1515
Description:Hycal probe 1000mm [R]
Ceramic Length:300mm
Total length:1000mm

HYC.PRB.003.012.1098

Drawing Number:3B1515
Description:Hycal probe 1200mm [MFC]
Ceramic Length:300mm
Total length:1200mm

HYC.PRB.003.012.347

Drawing Number:3B1515
Description:Hycal probe 1200mm [R]
Ceramic Length:300mm
Total length:1200mm

HYC.PRB.003.015.1099

Drawing Number:3B1515
Description:Hycal probe 1500mm [MFC]
Ceramic Length:300mm
Total length:1500mm

HYC.PRB.003.015.839

Drawing Number:3B1515
Description:Hycal probe 1500mm [R]
Ceramic Length:300mm
Total length:1500mm

HYC.PRB.003.016.1100

Drawing Number:3B1515
Description:Hycal probe 1600mm [MFC]
Ceramic Length:300mm
Total length:1600mm

HYC.PRB.003.016.421

Drawing Number:3B1515
Description:Hycal probe 1600mm [R]
Ceramic Length:300mm
Total length:1600mm

Need help?

If you can't find what you're looking for or need additional support, please contact our technical team.

Contact us
